Who is this for?

This guide is specifically for tradespeople. It covers what you need to do before and during installation.

Ground source heat pump outside a modern home

Advantages of a heat pump installation

  • Cheaper to run than oil and gas boilers
  • Reduce carbon emissions by using renewable heat from the air or ground
  • Highly efficient conversion rate of energy to heat
  • Options for cooling during the summer, making it an air conditioner

Step 1 - Choosing the right system for the property

How well a property is insulated plays an important role in the size of heat pump you select and how efficient it's going to be as, compared to a gas or oil boiler, heat pumps produce heat at a lower but more constant temperature. Things to consider include:

  • Cavity/wall insulation
  • Loft insulation
  • Double glazing

Also look at how well floors are insulated if you're dealing with a much older house.

If insulation or the age of the property is a concern, choose a hybrid system; this combines a heat pump with a small electric boiler to give a higher heat output.

For more advice, please call 01534 505460.

Step 2 - Complete an Electricity Supply Enquiry (ESE) form

Complete the ESE form to ensure the home's electricity service and local network can accept the additional load. This important step protects you and your customer!

The ESE form is an editable PDF. You can complete it using a computer, or print it and fill it out by hand.

Electricity Supply Enquiry

157kb
Download

Step 3 - Return the completed ESE to our team

By email

ese@jec.co.uk

By post / by hand

ESE Team
Jersey Electricity
The Powerhouse
Queens Road
St Helier JE4 8NY

By hand only

Customer Service desk at the Powerhouse

Step 4 - We confirm receipt of your application

Once we've received your completed ESE form, we will send you written confirmation and begin processing your application.

Step 5 - Plan your installation

Plan your installation. If you comply with our Approved Heating Guidelines, your customer can benefit from our Economy 20 Plus discounted heating tariff.

Step 6 - Changing tariff?

If your customer is changing tariff, you will also need to submit a Connection of Meter form quoting your ESE number from your confirmation letter.

Please send your completed form to our Metering Team by the following methods:

By email

meter@jec.co.uk

By post / by hand

Metering Team
Jersey Electricity
The Powerhouse
Queens Road
St Helier JE4 8NY

By hand only

La Collette Power Station Reception.

Connection of Meter form

164kb
Download

Step 7 - Installation

Air source heat pumps are usually positioned on the ground. They include an outdoor unit (the heat pump) and an indoor module connected to your heating system

Firstly, you need a suitable place to place the outdoor unit with reasonable clearance around it. This ideally needs to be sheltered from the elements and safe from tampering by passers-by.

Once both units are fitted on to their mountings, water or refrigerant and drain hose pipes are connected and insulated, inside and out. You can then connect the heat pump to the indoor heating system.

Step 8 - After installation

We recommend an annual inspection of air source heat pump and controls.

An electrician carries out maintenance.
